| ब्रांड नाम: | Raymo |
|---|---|
| प्रमाणन: | CE/RoHs/REACH/ISO9001:2015 |
| Model Number: | RM-2PM Series |
| Minimum Order Quantity: | 5 |
| मूल्य: | 1-9.99 USD |
| Delivery Time: | 2-3 WEEKS |
| भुगतान शर्तें: | टी/टी, डी/ए, डी/पी, वेस्टर्न यूनियन, मनीग्राम |
| Supply Ability: | 5000PCS Per Month |
| तापमान: | -60-200 | कार्य वोल्टेज: | ≤700V |
|---|---|---|---|
| वर्तमान मूल्यांकित: | 5-40A | संपर्क प्रतिरोध: | 0.8-5m n |
| उन्मुखीकरण: | सीधा/एंगल्ड | संपर्क: | 4/7/8/10/19/20/22/24/32/45/50 पिन |
| सामग्री: | एल्यूमीनियम मिश्र धातु | कनेक्टर प्रकार: | केबल प्लग /पैनल सॉकेट |
| प्रमुखता देना: | 2PM connector panel socket,aluminum alloy 2PM connector,2PM connector 5-40A 700V |
||
| Attribute | Value |
|---|---|
| Temperature | -60-200°C |
| Working Voltage | ≤700V |
| Rated Current | 5-40A |
| Contact resistance | 0.8-5mΩ |
| Orientation | Straight/Angled |
| Contacts | 4/7/8/10/19/20/22/24/32/45/50 Pin |
| Material | Aluminum Alloy |
| Connector type | Cable Plug / Panel Socket |
The 2PM Connector is a high-quality product designed for reliable electrical connections in various applications. With its Thread Connection method, this connector ensures a secure and stable connection between devices.
| Parameter | Value |
|---|---|
| Package Contents | 1 Connector |
| Rated Current | 5-40A |
| Contact resistance | 0.8-5mΩ |
| Connector type | Cable Plug / Panel Socket |
| Contacts | 4/7/8/10/19/20/22/24/32/45/50 Pin |
| Orientation | Straight/Angled |
| Temperature Range | -60-200°C |
| Connection Method | Thread Connection |
| Material | Aluminum Alloy |
| Working Voltage | ≤700V |
The 2PM Series Connector is suitable for various demanding applications including:
We offer customization services for the 2PM Connector with the following specifications:
| Brand Name | Raymo |
| Model Number | RM-2PM Series |
| Minimum Order Quantity | 5 |
| Price Range | 1-9.99 USD |
| Delivery Time | 2-3 weeks |
| Supply Ability | 5000PCS per month |
Our product comes with comprehensive technical support and services:
