| उत्पत्ति के प्लेस: | चीन |
|---|---|
| ब्रांड नाम: | Raymo |
| प्रमाणन: | CE/ROHS/REACH/SGS/ISO9001 |
| मॉडल संख्या: | HEG.0B.302.CLL |
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा |
| मूल्य: | 3.5-4.5 |
| पैकेजिंग विवरण: | पीई बैग + गत्ते का डिब्बा |
| प्रसव के समय: | 3-5 कार्य दिवस |
| भुगतान शर्तें: | एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम |
| आपूर्ति की क्षमता: | 500pcs/5-7 कार्य दिवस |
| प्रकार: | गोलाकार पुश पुल कनेक्टर | खोल का आकार: | 0 बी 1 बी 2 बी 3 बी 4 बी |
|---|---|---|---|
| संपर्क: | 2 पिन | रंग: | प्राकृतिक क्रोम मढ़वाया |
| लिंग: | महिला मिलाप संपर्क | आवेदन: | उच्च गति कैमरा |
| सामग्री/इन्सुलेटर डालें: | पी पी एस | आईपी रैंकिंग: | IP54 |
| प्रमुखता देना: | HGG Circular Cable Connectors,HEG 2 Pin Circular Power Connector,HGG 2 Pin Circular Connector |
||
PPS Insulator HEG HGG Circular Cable Connectors 2B Panel 2 Pin
HEG HGG 0B 1B 2B Panle Metal Socket Circular Push Pull Connector
Technical characteristics:
1. Endurance:> 5000 mating cycles
2. Humidity :Up to 95% at 60 ℃
3. Temperature range:-40 ℃, +250 ℃
4. Resistance to vibration :15 g[10 HZ-2000HZ]
5. Shock resistance:100 g ,6 MS
6. Salt spray corrosion test :> 96h
7. Protection index (mated) :IP50
RM-B series circular connectors provide the following main features:
1. Security of the Push-Pull self-latching system
2. Multiple key options to avoid cross mating
3. keying system («G» key standard)of similar connectors for connector alignment
4. 360° screening for full EMC shielding
5. Multi-pole types 2 to 46 contacts
6. Solder, print contacts (straight or elbow)
7. High packing density for space savings
RM-B series Shell size and Contacts of circular push pull connector
|
00B |
2pins 3pins 4pins |
|
0B |
2pins 3pins 4pins 5pins 6pins 7pins 9pins |
|
1B |
2pins 3pins 4pins 5pins 6pins 7pins 8pins pins 10pins 12pins 14pins 16 |
|
2B |
2pins 3pins 4pins 5pins 6pins 7pins 8pins 10pins 12pins 14pins 16pins 18pins 19pins 26 |
|
3B |
3pins 4pins 7pins 8pins 10pins 12pins 14pins 16pins 18pins 21pins 30pins |
Industry Application:
It is widely used on all kinds of medical equipments, specially for the signal transmission, Medical Equipment, Audio / Video, Test and Measurement, Communications prct line.
Company of Raymo:
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing
on manufacturing Creative customer-oriented metal and plastic circular push pull self latching connectors and
cable assemblies to serve over 75 countries and regions since 2010.
