| उत्पत्ति के प्लेस: | शेनझेन, चीन |
|---|---|
| ब्रांड नाम: | RAYMO |
| प्रमाणन: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| मॉडल संख्या: | GK0WCM-P12UM00-000L |
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा |
| मूल्य: | negotiable |
| पैकेजिंग विवरण: | 100 पीसी / सीटीएन |
| प्रसव के समय: | 5-8 कार्य दिवस |
| भुगतान शर्तें: | डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम, एल/सी |
| आपूर्ति की क्षमता: | 5000 पीसी/हप्ता |
| PRCT नाम: | एएमसी उच्च घनत्व पुश पुल कनेक्टर | संपर्कों की संख्या: | 12 संपर्क |
|---|---|---|---|
| आकार: | 0W | नमूना: | जीके |
| समाप्ति विधि: | मिलाप | लिंग से संपर्क करें: | महिला |
| आईपी रेटिंग: | IP68 | नमूना: | मुक्त |
| प्रमुखता देना: | High Density Circular Push Pull Connectors,0W Circular Push Pull Connectors,AMC Push Pull Connectors |
||
Prct intrce for AMC high-density Circular Push Pull Connectors
Raymo G series is compatible to RAYMO AMC High-Density series connector, which is a rugged, ultra-miniature connector solution for extreme environments.
The connector is available in two locking styles standard. Break-Away connectors can be easily disconnected by tugging on the cable, and are ideal whenever the cable is a potential snag hazard. Screw-Lock connectors remain connected despite environmental conditions, including tension on the cable, shock and vibration.
Prct details for AMC high-density Circular Push Pull Connectors
| Prct attribute | Attribute Value |
| Manufacturer | RAYMO |
| Prct name | Circular push pull connectors |
| Connector type | socket/receptacle |
| Contact Gender | Pole(Female) |
| Number of contacts | 12 contact |
| Mounting Style | Panel mount |
| Termination Style | Solder |
| Current Rating | 1-5A |
| IP Rating | IP68 |
| Shell Plating | Chrome |
| Shell Material | Metal |
| Wire Gauge | 28AWG |
| Certifications | ISO9001/ CE/ ROHS2.0/ SGS |
| Temperature Range | -55°C, +125°C |
| Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] |
| Salt spray corrosion test | >96hrs |
| Climatical Category | 50/175/21 |
| Humidity | Up to 95% at 60°C |
FEATURES for AMC high-density Circular Push Pull Connectors
• High contact-density connector
• Rugged, robust housing with non-reflective
surface plating
• Submersible, watertight protection classes
IP68 / IP69 / IP6K8 / IP6K9K
• Break-Away for maximum safety
• Mechanical coding with color-coded visual
indicator
APPLICATIONS for AMC high-density Circular Push Pull Connectors
• Tactical radios and accessories
• Ruggedized computers and tablets
• Power supply
• Unmanned systems
• Optical devices
• Software defined radios
• Defence and security systems
Our advantage
Original manufacturer
Excellent R&D team
10+ years experience
OEM & ODM acceptable
100% quality tested
100% fast delivery
100% after-sales service
Certificates for AMC high-density Circular Push Pull Connectors
CE
RoHS
ISO:9001-2015
SGS
REACH
