| उत्पत्ति के प्लेस: | चीन |
|---|---|
| ब्रांड नाम: | RAYMO |
| प्रमाणन: | ISO:9001-2015 |
| Model Number: | ECG.0B.304.CLN |
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा/टुकड़े |
| मूल्य: | negotiable |
| Packaging Details: | Plastic Bag & Carton |
| प्रसव के समय: | 5-7 कार्य दिवस |
| Payment Terms: | T/T, PAYPAL, EBAY |
| आपूर्ति की क्षमता: | 5000 टुकड़े/हप्ता |
| Shell size: | 0B series | Contact no.: | 4pin female contact |
|---|---|---|---|
| Prct Name: | PCB Connector | इन्सुलेटर: | पी पी एस |
| शेल सामग्री: | क्यूज़न | टर्मिनल: | पीसीबी |
| प्रमुखता देना: | circuit board connectors,pcb board connector |
||
| Connector Descitption Details: | |||
| Shell model | Straight plug FGG | Shell size | 00B 0B 1B 2B 3B 4B 5B |
| Gender | Male | Contact No. | 2,3,4,5,6,7,8,9,10,12,14,16,19,30,32, |
| MOQ | 1pc | Delivery | 2-5 working days |
| Endurance(shell) | 5000 mating cycles | Humidity | up to 95% at 60° C/140F |
| Technical Characteristics | |||
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 50 | Endurance(shell) | 5000 mating cycles |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
