| उत्पत्ति के प्लेस: | शेनझेन, चीन |
|---|---|
| ब्रांड नाम: | RAYMO |
| प्रमाणन: | CE ROHS2.0 ISO9001 REACH |
| Model Number: | FGG.2B.305.CLAD72Z |
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा/टुकड़े |
| मूल्य: | negotiable |
| Packaging Details: | Plastic Bag & Carton |
| प्रसव के समय: | 5-7 कार्य दिवस |
| Payment Terms: | T/T, D/A, D/P,L/C, MoneyGram, Western Union |
| आपूर्ति की क्षमता: | 5000 टुकड़े/हप्ता |
| Prct Name: | Push pull connector | Model: | Cable plug FGG assembled with RS232 |
|---|---|---|---|
| खोल का आकार: | 2 बी | Contact no.: | 5pin male contact |
| Insulator: | PPS, PEEK | Shell Color: | Silver chrome black chrome |
| प्रमुखता देना: | electronics component connectors,electronic cable connectors |
||
FGG.2B.305.CLAD72Z
Cable mount plug, 2B series shell size, 5pin male contact, 72cable collet for OD6.2-7.2mm cable, nut for a bend relief, 1 key, 0 degree, brass shell with natural chrome plated
assembledd with RS232 by overmoudling
cable can be twisted wire depend on custom options
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 68 | Endurance(shell) | 5000 mating cycles |
2020.11 Electronica Munich, Germany
2019.9.13-9.15 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
