| उत्पत्ति के प्लेस: | शेनझेन, चीन |
|---|---|
| ब्रांड नाम: | RAYMO |
| प्रमाणन: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| मॉडल संख्या: | पीकेजी |
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा |
| मूल्य: | negotiable |
| पैकेजिंग विवरण: | 100 पीसी / सीटीएन |
| प्रसव के समय: | 5-8 कार्य दिवस |
| भुगतान शर्तें: | डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम, एल/सी |
| आपूर्ति की क्षमता: | 5000 पीसी/हप्ता |
| PRCT नाम: | पुश पुल परिपत्र प्लास्टिक कनेक्टर | उन्नत संरचना: | स्व ताला |
|---|---|---|---|
| म्यूटिपल पिन: | 2-12 पिन | संपर्क: | मिलाप/पीसीबी/प्रिंट |
| आवेदन: | दंत उपकरण सेंसर कैथेटर | वर्तमान रेटिंग: | 2-10A |
| संरक्षण सूचकांक: | IP50 | लिंग: | महिला |
| प्रमुखता देना: | REACH Circular Plastic Connectors,12pins Circular Plastic Connectors,SGS Catheter Connector |
||
Female Circular Plastic Connectors Dental Equipment Sensors Catheter
Plastic Connector PKG Socket Dental Equipment Sensors Catheter Connector
1. Alternative Redel P series push pull plastic medical connector Prct Description:
RM-P series are mainly used in medical world. compatible with original, and these can be sterilizable. Single-use (called disposable connectors too) are also available when sterilization is not an option. The Push-Pull connectors are easy to manipulate and are available in IP50 and IP68 version.
These connectors can be used for a large variety of medical devices, for instance in the operating theatres and in intensive care.
Model type can be: PAG(G, A, B, C, H, J)
PKG(G, A, B, C, H, J)
PLG(G, A, B, C, H, J)
PRG(G, A, B, C, H, J)
Color options: gray(G), green(V), blue(A), black(N), red(R), white(W), yellow(Y).
2. Alternative Redel PKG push pull plastic connector techinical characteristics
| Prct attribute | Attribute Value |
| Manufacturer | RAYMO |
| Prct name | Circular push pull plastic connectors |
| Connector type | Panel mount receptacle |
| Contact Gender | Pin(Male)/Pole(Female) |
| Number of contacts | 2-14 contact |
| Mounting Style | Cable, Panel |
| Termination Style | Solder/PCB/Print |
| Current Rating | 2-10A |
| IP Rating | IP50 |
| Series | 1P |
| Contact Plating | Gold |
| Shell Material | PC |
| Certifications | ISO9001/ CE/ ROHS2.0/ SGS |
| Temperature Range | -40°C, +150°C |
| Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] |
| Salt spray corrosion test | >96hrs |
| Climatical Category | 50/175/21 |
| Cable assembly | Available |
3. Alternative Redel P series push pull plastic connector with below features:
•Push-pull self-locking system
•Mutiple pin: 2,3,4,5,6,7,8,9,10,12,14 pins optional
•Different keys for choose to aviod mix-mated.
•Colorful nuts for defferent machine request.
•Functional in a wide temperature range from -40°C to +150°C
•Available solder, PCB and right angle PCB contact
4. Alternative Redel P series push pull plastic connector Application
•Dental Equipment: Mixed configuration inserts, fluidic/pneumatic contact option, fiber optic (can be used for illumination).
•Disposable Devices (sensors, catheters): Reliable in a sensitive environment, plastic materials familiar to the medical industry. One time use solutions.
•Ventilators, anesthesia, intensive care: Connectors with a large choice of colors, immediately identifiable
