| उत्पत्ति के प्लेस: | शेनझेन, चीन |
|---|---|
| ब्रांड नाम: | RAYMO |
| प्रमाणन: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| मॉडल संख्या: | पैग/पीकेजी |
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा |
| मूल्य: | negotiable |
| पैकेजिंग विवरण: | 100 पीसी / सीटीएन |
| प्रसव के समय: | 5-8 कार्य दिवस |
| भुगतान शर्तें: | डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम, एल/सी |
| आपूर्ति की क्षमता: | 5000 पीसी/हप्ता |
| PRCT नाम: | पुश पुल परिपत्र प्लास्टिक कनेक्टर | उन्नत संरचना: | स्व ताला |
|---|---|---|---|
| म्यूटिपल पिन: | 2-12 पिन | संपर्क: | मिलाप/पीसीबी/प्रिंट |
| आवेदन: | परीक्षण और माप/चिकित्सा उपकरण/ऊर्जा/चरम | वर्तमान रेटिंग: | 2-10A |
| संरक्षण सूचकांक: | IP50 | लिंग: | पुरुष महिला |
| प्रमुखता देना: | IP50 Circular Plastic Connectors,SGS Circular Plastic Connectors,IP50 Medical Device Connector |
||
P Series PAG PKG IP50 Circular Plastic Connectors For Medical Device
Alternative Redel P Series PAG PKG Medical Device Plastic Connector
1. Alternative Redel P series push pull plastic connector Prct Description:
RAYMO P series plastic connector can compatible with original Redel P series, with more competitive price, high performance and short lead time, customer think highly of our connectors, and satisfied with the quality.
P series plastic connector are wildly use in area such as medical, industrial, test& meansurement, automotive...
Model type can be: PAG(G, A, B, C, H, J)
PKG(G, A, B, C, H, J)
PLG(G, A, B, C, H, J)
PRG(G, A, B, C, H, J)
Color options: gray(G), green(V), blue(A), black(N), red(R), white(W), yellow(Y).
2. Alternative Redel P series push pull plastic connector techinical characteristics
| Prct attribute | Attribute Value |
| Manufacturer | RAYMO |
| Prct name | Circular push pull plastic connectors |
| Connector type | Straight plug(PAG)/Panel mount receptacle(PKG/PLG)/Free receptacle(PRG) |
| Contact Gender | pIN(Male)/Pole(Female) |
| Number of contacts | 2-14 contact |
| Mounting Style | Cable, Panel |
| Termination Style | Solder/PCB/Print |
| Current Rating | 2-10A |
| IP Rating | IP50 |
| Series | 1P |
| Contact Plating | Gold |
| Shell Material | PC |
| Certifications | ISO9001/ CE/ ROHS2.0/ SGS |
| Temperature Range | -40°C, +150°C |
| Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] |
| Salt spray corrosion test | >96hrs |
| Climatical Category | 50/175/21 |
| Cable assembly | Available |
3. Alternative Redel P series push pull plastic connector with below features:
•Secure high performance push-pull self-locking system
•High pin density contributing to equipment miniaturization
•Contacts from 2-14pins
•Alignment Key and Polarized Keying System to avoid cross-interface
•Colorful nut for choice, easy for identify
•Functional in a wide temperature range from -40°C to +150°C
•Available solder, PCB and right angle PCB contact
4. Alternative Redel P series push pull plastic connector Application
•Medical electronics
•Test and measurement
•Industrial electronics
•Automotive
